DUP-360AN DIGITAL UNIVERSAL PROTRACTOR
Easy-to-read digital display.
Once setting the reference point (90°),angle measurement can be performed easily.
USE
●Precise angle measuring instrument used as angle measurement of machine, tooling and
fixtures, or for assembly, or as a reference standard
MATERIAL
●Blade: Stainless steel
FEATURES
●Display unit can be switched between 「°Jor「’」
●+-switchable
●Zero setting at desired angle
●Display orientation can be flipped 180
SPECIFICATIONS
●Measuring range: 360°
●Resolution: 1’.0.01
POWER
One CR2032(lithium) battery included for testing
ACCESSORIES
●Blade 150mm, 300mm
●Accurate angle attachment
●Master square
|
Model no. |
Accuracy |
Weght |
|
DUP-360AN |
±5’ (0.08°) |
350g |
